Description
| Brand | Dahua |
| Model | DHI-SSD-C900N128G |
| Details | |
| Capacity | 128GB |
| Interface | PCIe Gen 3.0 × 4 |
| Form Factor | M.2 2280 |
| Operating Temperature | 0 °C to +70 °C (+32 °F to +158 °F) |
| Storage Temperature | –40 °C to +85 °C (–40 °F to +185 °F) |
| Shock Resistance | 1500G&0.5 ms (half sine wave) |
| Power Consumption | 2950 mW (max) 528 mW (idle) |
| Memory Component | 3D NAND |
| Operating Humidity | 5%–95% (non-condensing) |
| Vibration Resistance | 10-200Hz, 0.5 G |
| 4K Random Read2 | Up to 90,000 |
| 4K Random Write2 | Up to 190,000 |
| MTBF | 1,500,000 hours |
| TBW | 80 TB |
| Reference Information | 1.Capacity calculation: 1 GB = 1 billion bytes (IDEMA). Actual available capacity might be reduced (due to formatting, partition, operating system applications, or other necessary usage); 2. System configuration of performance test: Chip-AMD Ryzen 5 5600X 6-Core [email protected] GHz, 8G-DDR4, operating system-Windows 10 x64, testing tool-CrystalDiskMark 6.0.0 x64; 3.Warranty period or maximum write amount (TBW), whichever comes first; 4.High performance SLC cache has been enabled; 5.*The speed data comes from Zhejiang Huayixin Technology Co., Ltd Lab. The actual performance might differ depending on the device it is being used with. |
| Performance | |
| Max Sequential Read | 1250MB/s |
| Max Sequential Write | 650MB/s |
| Dimensions & Weight | |
| Weight | Max. 8 g (0.02 lb) |
| Product Dimensions | 80.00 mm × 22.00 mm × 2.25 mm (3.15″ × 0.87″ × 0.09″) |
| Packaging Dimensions | 140.5 mm × 105.5 mm × 15.50 mm (5.53″ × 4.15″ × 0.61″) |
| Warranty | |
| Warranty | 3 years limited warranty |
